Description and features
Our angle glider has been designed to be used for end of traverses.
RAL colors manufactured
the following references are also available in environment friendly materials. Contact our Commercial Office for more information.Product images and technical drawings
Product view
Technical drawing
Video
Part numbers and dimensions of Round tube insert for end of traverses
| Reference | For Tube (D) |
Tube Thickness |
L |
H |
h |
L1 |
Hole Diameter |
More Info. |
|||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 00300400742 | 20 | 1,50 a 2,00 | 46,00 | 4,80 | 7,00 | ||||||||
| 00300400743 | 25 | 1,50 a 2,00 | 65,50 | 7,50 | 6,50 | 49,00 | 5,20 | ||||||
| 00300400744 | 28 | 2,00 | 64,50 | 7,50 | 6,00 | 48,00 | 5,20 | ||||||
| 00300400745 | 30 | 2,00 | 44,70 | 6,00 | 7,00 | 20,00 | 5,20 | ||||||
| 00300400746 | 32 | 1,50 | 52,00 | 8,20 | 6,50 | 30,00 | 5,50 | ||||||
| 00300400747 | 35 | 1,50 | 52,00 | 6,00 | 10,00 | 28,00 | 5,20 | ||||||
| 00300400748 | 35 | 2,00 | 52,00 | 6,00 | 8,00 | 27,00 | 6,00 | ||||||
| 00300400749 | 35 | 2,50 | 52,00 | 6,00 | 7,50 | 28,00 | 5,20 | ||||||
| 00300400750 | 38 | 2,00 | 52,00 | 8,20 | 6,50 | 29,50 | 5,50 | ||||||
| 00300400751 | 40 | 2,50 | 51,00 | 6,00 | 7,00 | 28,00 | 5,20 |
