Our trimming cover has been designed in order to hide adjustable feet of square tubes. We recommend its use with our ribbed inserts for square tubes LJ and LJM with nut fixed with adjustable feet, and our adjustable feet range.
 RAL colors manufactured

Drawing PDF:
UL94:
IP:
RoHS:
Measures expressed in: Millimeters
BIO Line: BIO LINE the following references are also available in environment friendly materials. Contact our Commercial Office for more information.


Reference
For tube
D
A
B
d
L



More
Info.
00301200762 25 x 25 36,50 28,50 25,50 33,00 70,00
00301200763 30 x 30 43,60 33,50 30,50 40,00 70,00

If you are interested in our family LRQ, you may be interested in these families as well:

The ribbed threaded inserts LJ for square tubes are offered in different designs and sizes. The metric nut, which is incorporated during the injection process, offers a strong fixation. The combination of the available sizes and materials (LDPE and PA6) will offer different properties, such as resistance to weight (we recommend carrying out tests through a sample order).   Our adjustable foot has a knurled base for easier handling.
