Our 3-way connector has been designed for square tubes. It is supplied with an internal metal core. It has a thread of M8 or M10, depending on the reference.
 RAL colors manufactured

Drawing PDF:
UL94:
IP:
RoHS:
Measures expressed in: Millimeters

THCYB
THCYB

Reference
For Tube
Tube Thickness
L
H
Metric (M)



More
Info.
02300400052 25 x 25 1,50 50,00 25,00 M8
02300400053 25 x 25 1,50 52,00 25,00 M10
02300400054 30 x 30 2,00 47,00 30,00 M8
02300400055 30 x 30 2,00 47,00 30,00 M10

If you are interested in our family THCYB, you may be interested in these families as well:

  Our round adjustable foot has a steel cover. If you need it with an hexagonal nut for an easier assembly, see our family LHDE. If you want the part with movement or tilting, please visit our family MFDD.   The screw of our adjustable foot is in zinc coated steel, the cover in stainless steel and the base in polipropylene. The part is available without cover, please see our family LHVD. The hex nut of the adjustable foot allows easier fitting. There is a little space between the hexagonal nut and the base, that allows small movement of the screw, in an angle of about 3º.   Our 3-way connector has been designed in order to connect square tubes. It is supplied without internal metal core.
