Our adjustable foot with a hexagonal screw for easier fitting.

Material:  PP   PA6   ZCS
Standard colors: Black / RAL colors manufactured
Drawing PDF:
UL94:
IP:
RoHS:
Measures expressed in: Millimeters


Reference
Metric Thread (M)
L
D
H
Max. Tilting degree (W)



More
Info.
00301200191 M8 16,00 20,00 15,50
00700500050 M8 16,00 20,00 16,00
00301200213 M8 16,00 23,00 15,50
00700500072 M8 16,00 25,00 16,00
00301200235 M8 16,00 28,00 15,50
00700500103 M8 16,00 30,00 16,00
00301200265 M8 16,00 33,00 15,50
00700500134 M8 16,00 40,00 15,00
00301200192 M8 20,00 20,00 15,50
00700500051 M8 20,00 20,00 16,00
00301200214 M8 20,00 23,00 15,50
00700500073 M8 20,00 25,00 16,00
00301200236 M8 20,00 28,00 15,50
00700500104 M8 20,00 30,00 16,00
00301200266 M8 20,00 33,00 15,50
00700500135 M8 20,00 40,00 15,00
00301200193 M8 30,00 20,00 15,50
00700500052 M8 30,00 20,00 16,00
00301200215 M8 30,00 23,00 15,50
00700500074 M8 30,00 25,00 16,00
00301200237 M8 30,00 28,00 15,50
00700500105 M8 30,00 30,00 16,00
00301200267 M8 30,00 33,00 15,50
00700500136 M8 30,00 40,00 15,00
00301200194 M8 40,00 20,00 15,50
00700500053 M8 40,00 20,00 16,00
00301200216 M8 40,00 23,00 15,50
00700500075 M8 40,00 25,00 16,00
00301200238 M8 40,00 28,00 15,50
00700500106 M8 40,00 30,00 16,00
00301200268 M8 40,00 33,00 15,50
00700500137 M8 40,00 40,00 15,00
00301200195 M8 50,00 20,00 15,50
00700500054 M8 50,00 20,00 16,00
00301200217 M8 50,00 23,00 15,50
00700500076 M8 50,00 25,00 16,00
00301200239 M8 50,00 28,00 15,50
00700500107 M8 50,00 30,00 16,00
00301200269 M8 50,00 33,00 15,50
00700500138 M8 50,00 40,00 15,00
00301200196 M8 60,00 20,00 15,50
00700500055 M8 60,00 20,00 16,00
00301200218 M8 60,00 23,00 15,50
00700500077 M8 60,00 25,00 16,00
00301200240 M8 60,00 28,00 15,50
00700500108 M8 60,00 30,00 16,00
00301200270 M8 60,00 33,00 15,50
00700500139 M8 60,00 40,00 15,00
00301200197 M8 70,00 20,00 15,50
00700500056 M8 70,00 20,00 16,00
00301200219 M8 70,00 23,00 15,50
00700500078 M8 70,00 25,00 16,00
00301200241 M8 70,00 28,00 15,50
00700500109 M8 70,00 30,00 16,00
00301200271 M8 70,00 33,00 15,50
00700500140 M8 70,00 40,00 15,00
00301200198 M8 80,00 20,00 15,50
00700500057 M8 80,00 20,00 16,00
00301200220 M8 80,00 23,00 15,50
00700500079 M8 80,00 25,00 16,00
00301200242 M8 80,00 28,00 15,50
00700500110 M8 80,00 30,00 16,00
00301200272 M8 80,00 33,00 15,50
00700500141 M8 80,00 40,00 15,00
00301200199 M8 90,00 20,00 15,50
00700500058 M8 90,00 20,00 16,00
00301200221 M8 90,00 23,00 15,50
00700500080 M8 90,00 25,00 16,00
00301200243 M8 90,00 28,00 15,50
00700500111 M8 90,00 30,00 16,00
00301200273 M8 90,00 33,00 15,50
00700500142 M8 90,00 40,00 15,00
00301200200 M8 100,00 20,00 15,50
00700500059 M8 100,00 20,00 16,00
00301200222 M8 100,00 23,00 15,50
00700500081 M8 100,00 25,00 16,00
00301200244 M8 100,00 28,00 15,50
00700500112 M8 100,00 30,00 16,00
00301200274 M8 100,00 33,00 15,50
00700500143 M8 100,00 40,00 15,00
00301200201 M8 120,00 20,00 15,50
00700500060 M8 120,00 20,00 16,00
00301200223 M8 120,00 23,00 15,50
00700500082 M8 120,00 25,00 16,00
00301200245 M8 120,00 28,00 15,50
00700500113 M8 120,00 30,00 16,00
00301200275 M8 120,00 33,00 15,50
00700500144 M8 120,00 40,00 15,00
00301200202 M10 16,00 20,00 16,50
00700500061 M10 16,00 20,00 16,50
00301200224 M10 16,00 23,00 16,50
00700500083 M10 16,00 25,00 16,50
00301200246 M10 16,00 28,00 16,50
00700500114 M10 16,00 30,00 16,50
00301200276 M10 16,00 33,00 16,50
00700500145 M10 16,00 40,00 16,50
00301200203 M10 20,00 20,00 16,50
00700500062 M10 20,00 20,00 16,50
00301200225 M10 20,00 23,00 16,50
00700500084 M10 20,00 25,00 16,50
00301200247 M10 20,00 28,00 16,50
00700500115 M10 20,00 30,00 16,50
00301200277 M10 20,00 33,00 16,50
00700500146 M10 20,00 40,00 16,50
00301200204 M10 30,00 20,00 16,50
00700500063 M10 30,00 20,00 16,50
00301200226 M10 30,00 23,00 16,50
00700500085 M10 30,00 25,00 16,50
00301200248 M10 30,00 28,00 16,50
00700500116 M10 30,00 30,00 16,50
00301200278 M10 30,00 33,00 16,50
00700500147 M10 30,00 40,00 16,50
00301200205 M10 40,00 20,00 16,50
00700500064 M10 40,00 20,00 16,50
00301200227 M10 40,00 23,00 16,50
00700500086 M10 40,00 25,00 16,50
00301200249 M10 40,00 28,00 16,50
00700500117 M10 40,00 30,00 16,50
00301200279 M10 40,00 33,00 16,50
00700500148 M10 40,00 40,00 16,50
00301200206 M10 50,00 20,00 16,50
00700500065 M10 50,00 20,00 16,50
00301200228 M10 50,00 23,00 16,50
00700500087 M10 50,00 25,00 16,50
00301200250 M10 50,00 28,00 16,50
00700500118 M10 50,00 30,00 16,50
00301200280 M10 50,00 33,00 16,50
00700500149 M10 50,00 40,00 16,50
00301200207 M10 60,00 20,00 16,50
00700500066 M10 60,00 20,00 16,50
00301200229 M10 60,00 23,00 16,50
00700500088 M10 60,00 25,00 16,50
00301200251 M10 60,00 28,00 16,50
00700500119 M10 60,00 30,00 16,50
00301200281 M10 60,00 33,00 16,50
00700500150 M10 60,00 40,00 16,50
00301200208 M10 70,00 20,00 16,50
00700500067 M10 70,00 20,00 16,50
00301200230 M10 70,00 23,00 16,50
00700500089 M10 70,00 25,00 16,50
00301200252 M10 70,00 28,00 16,50
00700500120 M10 70,00 30,00 16,50
00301200282 M10 70,00 33,00 16,50
00700500151 M10 70,00 40,00 16,50
00301200209 M10 80,00 20,00 16,50
00700500068 M10 80,00 20,00 16,50
00301200231 M10 80,00 23,00 16,50
00700500090 M10 80,00 25,00 16,50
00301200253 M10 80,00 28,00 16,50
00700500121 M10 80,00 30,00 16,50
00301200283 M10 80,00 33,00 16,50
00700500152 M10 80,00 40,00 16,50
00301200210 M10 90,00 20,00 16,50
00700500069 M10 90,00 20,00 16,50
00301200232 M10 90,00 23,00 16,50
00700500091 M10 90,00 25,00 16,50
00301200254 M10 90,00 28,00 16,50
00700500122 M10 90,00 30,00 16,50
00301200284 M10 90,00 33,00 16,50
00700500153 M10 90,00 40,00 16,50
00301200211 M10 100,00 20,00 16,50
00700500070 M10 100,00 20,00 16,50
00301200233 M10 100,00 23,00 16,50
00700500092 M10 100,00 25,00 16,50
00301200255 M10 100,00 28,00 16,50
00700500123 M10 100,00 30,00 16,50
00301200285 M10 100,00 33,00 16,50
00700500154 M10 100,00 40,00 16,50
00301200212 M10 120,00 20,00 16,50
00700500071 M10 120,00 20,00 16,50
00301200234 M10 120,00 23,00 16,50
00700500093 M10 120,00 25,00 16,50
00301200256 M10 120,00 28,00 16,50
00700500124 M10 120,00 30,00 16,50
00301200286 M10 120,00 33,00 16,50
00700500155 M10 120,00 40,00 16,50
00700500094 M12 30,00 25,00 18,00
00301200257 M12 30,00 28,00 17,50
00700500125 M12 30,00 30,00 18,00
00301200287 M12 30,00 33,00 17,50
00700500156 M12 30,00 40,00 18,00
00700500095 M12 40,00 25,00 18,00
00301200258 M12 40,00 28,00 17,50
00700500126 M12 40,00 30,00 18,00
00301200288 M12 40,00 33,00 17,50
00700500157 M12 40,00 40,00 18,00
00700500096 M12 50,00 25,00 18,00
00301200259 M12 50,00 28,00 17,50
00700500127 M12 50,00 30,00 18,00
00301200289 M12 50,00 33,00 17,50
00700500158 M12 50,00 40,00 18,00
00700500097 M12 60,00 25,00 18,00
00301200260 M12 60,00 28,00 17,50
00700500128 M12 60,00 30,00 18,00
00301200290 M12 60,00 33,00 17,50
00700500159 M12 60,00 40,00 18,00
00700500098 M12 70,00 25,00 18,00
00301200261 M12 70,00 28,00 17,50
00700500129 M12 70,00 30,00 18,00
00301200291 M12 70,00 33,00 17,50
00700500160 M12 70,00 40,00 18,00
00700500099 M12 80,00 25,00 18,00
00301200262 M12 80,00 28,00 17,50
00700500130 M12 80,00 30,00 18,00
00301200292 M12 80,00 33,00 17,50
00700500161 M12 80,00 40,00 18,00
00700500100 M12 90,00 25,00 18,00
00301200263 M12 90,00 28,00 17,50
00700500131 M12 90,00 30,00 18,00
00301200293 M12 90,00 33,00 17,50
00700500162 M12 90,00 40,00 18,00
00700500101 M12 100,00 25,00 18,00
00301200264 M12 100,00 28,00 17,50
00700500132 M12 100,00 30,00 18,00
00301200294 M12 100,00 33,00 17,50
00700500163 M12 100,00 40,00 18,00
00700500102 M12 120,00 25,00 18,00
00700500133 M12 120,00 30,00 18,00
00700500164 M12 120,00 40,00 18,00

If you are interested in our family LHVT, you may be interested in these families as well:

Our threaded insert is manufactured in Zamak alloy for oval tubes. It is also available for square tubes: LJM, round tubes: LJMR and for rectangular tubes: LJMZ.   Our threaded insert is manufactured in Zamak alloy for rectangular tubes. It is also available for round tubes: LJMR, square tubes: LJM and for oval tubes: LJMO.   Our round reinforced tube inserts allow to assemble structures of tubes on levelling feet quickly. It has a nickel-plated brass threaded insert inside, which has been inserted during the injection process. It is also available for square tubes: JTPOA.   Our threaded end pieces with square tube thread have been designed for applications that must be highly resistant. The threaded insert is made of Nickel Plated Brass. It is also available in Stainless Steel. For other dimensions that do not appear in the list, contact us.   Our threaded triangular tube insert is also available for square tubes: JTPO, for rectangular tubes: LJZ, for round tubes: JTPU, and for oval tubes: LJMT.   Our ribbed insert for oval tubes has a metal nut inserted during the injection process. It is also available for square tubes: JTPO, rectangular tubes: LJZ, round tubes: LJRL, and triangle tubes: LJZZ.   Our ribbed insert for square tubes has a metal nut inserted during the injection process. It is also available for rectangular tubes: LJZ, round: LJRL, and triangle tubes: LJZZ. Parts with greater h dimension (nut insertion height), are recommended for heavy-duty applications.   Our ribbed insert for rectangular tubes has a metal nut inserted during the injection process. It is also available for square tubes: LJ, round tubes LJRL, and triangle tubes: LJZZ. It is suitable with our adjustable feet group.   Our ribbed insert is for round tubes. It has been designed in two parts, with a hexagon metal nut in the inside.   Our round tube insert has been designed with an hexagonal nut. The nut is inserted during the injection process. The part has an excellent finished and a good resistance. It is suitable for our adjustable feet, see our Adjustable feet section.
