Description and features
The square threaded reinforced tube inserts JTPOA are made of glass fiber reinforced polyamide (PA6630%GF), a material that offers excellent resistance. While the nuts are made of nickel-plated brass (NB) and 304 stainless steel (SS).These inserts are ideal for applications that require supporting high weights, as they reach resistances from 560 to almost 1,000 kilograms.
RAL colors manufactured Product images and technical drawings
Product view
Technical drawing
Video
| 04600800050 | 30 x 30 | 1,50 | M8 | 27,00 | 27,50 | 6,00 | 560 | 5.500 | |||||
| 00300410015 | 30 x 30 | 1,50 | M10 | 33,00 | 27,50 | 6,00 | 560 | 5.500 | |||||
| 00300410016 | 30 x 30 | 1,50 | M12 | 27,00 | 27,50 | 6,00 | 560 | 5.500 | |||||
| 04600800051 | 30 x 30 | 1,50 | M14 | 33,00 | 27,50 | 6,00 | 560 | 5.500 | |||||
| 04600800052 | 30 x 30 | 1,50 | M16 | 33,00 | 27,50 | 6,00 | 560 | 5.500 | |||||
| 04600800053 | 35 x 35 | 1,50 | M8 | 43,00 | 32,50 | 8,50 | 713 | 7.000 | |||||
| 04600800054 | 35 x 35 | 1,50 | M10 | 43,00 | 32,50 | 8,00 | 713 | 7.000 | |||||
| 04600800055 | 35 x 35 | 1,50 | M12 | 43,00 | 32,50 | 8,50 | 713 | 7.000 | |||||
| 04600800056 | 35 x 35 | 1,50 | M14 | 43,00 | 32,50 | 8,00 | 713 | 7.000 | |||||
| 04600800057 | 35 x 35 | 1,50 | M16 | 43,00 | 32,50 | 8,00 | 713 | 7.000 | |||||
| 04600800059 | 40 x 40 | 1,50 | M8 | 43,00 | 37,50 | 8,00 | 815 | 8.000 | |||||
| 01200100200 | 40 x 40 | 1,50 to 2,00 | M10 | 30,00 | 38,00 | 5,50 | 800 | 7.845 | |||||
| 00300410017 | 40 x 40 | 1,50 | M10 | 43,00 | 37,50 | 8,00 | 815 | 8.000 | |||||
| 01200100201 | 40 x 40 | 1,50 to 2,00 | M12 | 30,00 | 38,00 | 5,50 | 800 | 7.845 | |||||
| 00300410019 | 40 x 40 | 1,50 | M12 | 43,00 | 37,50 | 8,00 | 815 | 8.000 | |||||
| 01200100202 | 40 x 40 | 1,50 to 2,00 | M14 | 30,00 | 38,00 | 5,50 | 800 | 7.845 | |||||
| 04600800060 | 40 x 40 | 1,50 | M14 | 43,00 | 37,50 | 8,00 | 815 | 8.000 | |||||
| 01200100203 | 40 x 40 | 1,50 to 2,00 | M16 | 30,00 | 38,00 | 5,50 | 800 | 7.845 | |||||
| 00300410021 | 40 x 40 | 1,50 | M16 | 43,00 | 37,50 | 8,00 | 815 | 8.000 | |||||
| 01200100204 | 40 x 40 | 1,50 to 2,00 | M20 | 30,00 | 38,00 | 5,50 | 800 | 7.845 | |||||
| 04600800061 | 40 x 40 | 1,50 | M20 | 43,00 | 37,50 | 8,00 | 815 | 8.000 | |||||
| 04600800062 | 40 x 40 | 2,00 | M8 | 43,00 | 36,50 | 8,00 | 815 | 8.000 | |||||
| 00300410018 | 40 x 40 | 2,00 | M10 | 43,00 | 36,50 | 8,00 | 815 | 8.000 | |||||
| 00300410020 | 40 x 40 | 2,00 | M12 | 43,00 | 36,50 | 8,00 | 815 | 8.000 | |||||
| 04600800063 | 40 x 40 | 2,00 | M14 | 35,00 | 40,00 | 8,00 | 815 | 8.000 | |||||
| 00300410022 | 40 x 40 | 2,00 | M16 | 43,00 | 36,50 | 8,00 | 815 | 8.000 | |||||
| 00300410023 | 40 x 40 | 2,00 | M20 | 43,00 | 36,50 | 8,00 | 815 | 8.000 | |||||
| 01200100304 | 50 x 50 | 1,50 | M12 | 44,00 | 47,80 | 8,00 | 800 | 7.845 | |||||
| 00300410024 | 50 x 50 | 1,50 | M12 | 55,00 | 47,50 | 10,00 | 968 | 9.500 | |||||
| 01200100305 | 50 x 50 | 1,50 | M14 | 30,00 | 47,80 | 5,50 | 800 | 7.845 | |||||
| 04600800064 | 50 x 50 | 1,50 | M14 | 55,00 | 47,50 | 10,00 | 968 | 9.500 | |||||
| 01200100306 | 50 x 50 | 1,50 | M16 | 30,00 | 47,80 | 5,50 | 800 | 7.845 | |||||
| 00300410025 | 50 x 50 | 1,50 | M16 | 55,00 | 47,50 | 10,00 | 968 | 9.500 | |||||
| 01200100307 | 50 x 50 | 1,50 | M20 | 30,00 | 47,80 | 5,50 | 800 | 7.845 | |||||
| 04600800065 | 50 x 50 | 1,50 | M20 | 55,00 | 47,50 | 10,00 | 968 | 9.500 | |||||
| 01200100300 | 50 x 50 | 2,00 | M12 | 30,00 | 46,80 | 5,50 | 800 | 7.845 | |||||
| 01200100301 | 50 x 50 | 2,00 | M14 | 30,00 | 46,80 | 5,50 | 800 | 7.845 | |||||
| 01200100302 | 50 x 50 | 2,00 | M16 | 30,00 | 46,80 | 5,50 | 800 | 7.845 | |||||
| 01200100303 | 50 x 50 | 2,00 | M20 | 30,00 | 46,80 | 5,50 | 800 | 7.845 | |||||
| 04600800066 | 50 x 50 | 2,50 | M12 | 45,00 | 50,00 | 10,00 | 968 | 9.500 | |||||
| 04600800067 | 50 x 50 | 2,50 | M14 | 55,00 | 45,50 | 10,00 | 968 | 9.500 | |||||
| 00300410026 | 50 x 50 | 2,50 | M16 | 55,00 | 45,50 | 10,00 | 968 | 9.500 | |||||
| 00300410027 | 50 x 50 | 2,50 | M20 | 55,00 | 45,50 | 10,00 | 968 | 9.500 |
